3/2D-HH Slurry Pump Volute Liner Seal DH2125S51

Product Brands: Tobee

DH2125 Volute Liner Seal Fit over periphery of Volute Liner Seal Frame Plate Liner Insert.

price:

$78.40 $80.00

Materials:

S51 S42 S12 S01 S02 R55

Part #:

DH2125S51

Pump model:

3/2D-HH Slurry Pump

Quantity:

- + (200 available)

Add to Favorite Items (300)

Sales: 209+

DH2125 Volute Liner Seal fit over periphery of Frame Plate Liner Insert, Slurry pump volute seals are normally made in rubber like R55,S42,S12,S10,S01, S51and slurry pump volute seals are also available to suit: AH slurry pumps, L slurry pumps, M slurry pumps, HH slurry pumps, G and GH gravel pumps.

Volute liner seal function is the rubber seal installed on a slurry pump between the volute liner and the frame plate to keep the fluid from leaking. All volute liner seals will be seen only on metal slurry pumps.

3/2D-HH high head slurry pump parts list:

Item	Pump Type	Part Code	Description	Material	Weight (kgs)
1	3/2D-HH	C2060	Intake Joint	Rubber
2	3/2D-HH	C2132XLP	Discharge Joint Ring	Rubber
3	3/2D-HH	D138	Grease Cup Adaptor	Alloy 20	0.29
4	3/2D-HH	D075	Shaft Sleeve	C23	5.73
5	3/2D-HH	D003M	Pump Base	D21	77.5
6	3/2D-HH	D063	Lantern Ring	C23	2.21
7	3/2D-HH	D118	Lantern Restrictor	C23	2.88
8	3/2D-HH	D067	Neck Ring	C23	0.85
9	3/2D-HH	D044	Gland Assembly	D21	1.87
10	3/2D-HH	D090	Lip Seal	Rubber(S12)
11	3/2D-HH	D109	Shaft O-Ring	Rubber(S12)
12	3/2D-HH	DAM117	Shaft Spacer	C23	3.49
13	3/2D-HH	E122	Expeller Ring/stuffing box seal	Rubber
14	3/2D-HH	DH2032	Frame Plate (QT)	D21	132
15	3/2D-HH	DH2013	Cover Plate (QT)	D21	137
16	3/2D-HH	DH2147	Impeller (A05)	A05	78
17	3/2D-HH	DH2110	Volute Liner (A05)	A05	71
18	3/2D-HH	DH2083	Throath bush (A05)	A05	48
19	3/2D-HH	DH2041	Frame Plate Liner Insert (A05)	A05	43.35
20	3/2D-HH	DH078	Stuffing Box	D21	21.67
21	3/2D-HH	DAM028	Expeller	D21	8.2
22	3/2D-HH	DAM028	Expeller (A05)	A05	10
23	3/2D-HH	DAM029	Expeller Ring	D21	17.6
24	3/2D-HH	DAM029	Expeller Ring (A05)	A05	17.6
25	3/2D-HH	DH2302	Lifting Tube	Alloy 20	11.55
26	3/2D-HH	DH2304	Volute Lifting Beam	Alloy 20	15.99
27	3/2D-HH	E4015M	Cover Plate Bolt	E65	3.19
28	3/2D-HH	F064	Shaft O-Ring	Rubber(S12)
29	3/2D-HH	DH2125	Volute Liner Seal	Rubber
30	3/2D-HH	EP122	Expeller Ring / Stuffing Box Seal	Rubber(S12)
31	3/2D-HH	D004M	Bearing Body	D21	35.5
33	3/2D-HH	DAM073M	Shaft	E65	40.56
35	3/2D-HH	D024	End Cover	D21	4.3
36	3/2D-HH	D062	Labyrinth	D21	2.4
37	3/2D-HH	SBB048-82	Clamp Washer D011	E65	0.44
38	3/2D-HH	SBB049-82	Adjusting Screw (M20X185)	E65	0.69
39	3/2D-HH	SBB050-82	Cotter 150X35	A3.A3F	0.24
40	3/2D-HH	SBB051-82	Cover Plate Bolt (M20X220)	E65	0.96
41	3/2D-HH	SBB054-82	Square head screw (M16X110)	E65	0.39
42	3/2D-HH	DAM005M	Bearing Assembly

Label: Warman Rubber Slurry Pump Parts Rubber Slurry Pump Spares 3/2D-HH Slurry Pump
