SPR65QV Vertical Slurry Pump Rubber Impeller SPR65206R55

(0 Reviews)

TB-SPR65206R55

Product Brands: Tobee

SPR65206R55 Impeller is best important wear parts for SPR65QV Rubber Lined Vertical Slurry Pumps.

price:

$320.00 $420.00

Part Code:

SPR65206R55

Pump model:

65QV-SPR

Quantity:

- + (240 available)
Add to Favorite Items (0)

Sales: 0+

SPR65206R55 Impeller is best important wear parts for SPR65QV Rubber Lined Vertical Slurry Pumps.



Impeller SPR65206 - Double suction impellers (top and bottom entry) induce low axial bearing loads and have heavy deep vanes for maximum wear resistance and for handling large solids. Wear resistant alloys, polyurethane and moulded elastomer impellers are interchangeable. The impeller is adjusted axially within the casting during assembly by external shims under the bearing housing feet. No further adjustment is necessary.

Casing SPR65092 - Has a simple bolt-on attachment to the base of the column. It is manufactured from a wear resistant alloy for the SP and from moulded elastomer for the SPR.

Back Liner SPR65041 - It forms a pump chamber with throat bush and volute liner where the slurry would flow through them, Tobee offers back liners are interchangeable with stardand pump back liners with high chrome, natural rubber, polyurethane for different working condition.

Vertical Slurry Pump Parts:
• Bearing Assembly - The bearings, shaft and housing are generously proportioned to avoid problems associated with the operation of cantilevered shafts in the first critical speed zones. The assembly is grease lubricated and sealed by labyrinths; the upper is grease purged and the lower protected by a special flinger. The upper or drive end bearing is a parallel roller type whilst the lower bearing is a double taper roller with preset end float. This high performance bearing arrangement and robust shaft eliminates the need for a lower submerged bearing.
• Column Assembly - Completely fabricated from mild steel. The SPR model is elastomer covered.
• Discharge Pipe - Metal for SP, elastomer covered for SPR. All wetted metal parts are completely rust protected.
• Submerged Bearings - None
• Agitation - An external agitator spray connection arrangement can be fitted to the pump as an option. Alternatively, a mechanical agitator is fitted to an extended shaft protruding from the impeller eye.
• Materials - Pumps can be manufactured in abrasive and corrosive resistant materials.

65QV-SPR Rubber Lined Vertical Slurry Pumps Applications:
The SPR and SP designs, manufactured in popular metric sizes, provide a simple, yet rugged range of sump pumps specially developed for: Abrasive and/or corrosive slurries, Large particle size, High slurry densities, Continuous or “snore” operations,Heavy duties demanding cantilevered shafts in minerals processing, coal preparation, chemical processing, effluent handling, sand and gravel, and almost every other tank, pit or hole-in-the-ground slurry handling situation.



SPR65QV Vertical Slurry Pump Parts List:

No.

Pump Model

Part Name

Basic Part No.

Part Code

Material

1

65QV-SPR

Bearing Housing

004

QV004-1

Ductile

2

65QV-SPR

Bearing Sleeve

008

QV008

-

3

65QV-SPR

Bearing

009

Q009

SKF/Timken (Standard)

4

65QV-SPR

Bearing

009D

Q009D-1

SKF/Timken (Standard)

5

65QV-SPR

Mounting Plate

019

QVR65019

Steel

6

65QV-SPR

End Cover

024

QV024

Ductile

7

65QV-SPR

Low End Cover

024L

QV024L-1

Steel

8

65QV-SPR

Key

-

QV070

Steel

9

65QV-SPR

Washer

-

60

Steel

10

65QV-SPR

Shim Set

025

QV025

-

11

65QV-SPR

Nipple

-

M10X1

Steel

12

65QV-SPR

Name Plate

-

-

-

13

65QV-SPR

Rivet

-

-

Steel

14

65QV-SPR

Back Liner

041

SPR65041

Rubber

15

65QV-SPR

Suction Joint

060

SPR65060

-

16

65QV-SPR

Lock Nut

061

QV061

Steel

17

65QV-SPR

Labyrinth

062

QV062

Steel

18

65QV-SPR

Nipple 45

-

M10X1

Steel

19

65QV-SPR

O Ring

064

QV064

Ductile

20

65QV-SPR

Shaft

073

QVR65073

Steel

21

65QV-SPR

Shaft Sleeve Ejector

077

QV077

-

22

65QV-SPR

Bearing Seal

089

QV089

-

23

65QV-SPR

Casing

092

SPR65092

Rubber

24

65QV-SPR

Column

102

QVR65102

-

25

65QV-SPR

Piston Ring

108

Q108

Steel

26

65QV-SPR

End Cover Set Screw

-

D027M

Steel

27

65QV-SPR

Strainer

116

SPR65116-1

Rubber

28

65QV-SPR

Socket Head Protector

-

M20-291

-

29

65QV-SPR

Column Clamp

153

SPR65153

-

30

65QV-SPR

Discharge Pipe

154

QVR65154

-

31

65QV-SPR

Flinger

184

QV184-1

-

32

65QV-SPR

Impeller

206

SPR65206A

Rubber

33

65QV-SPR

O Ring

217

QV217

Steel

34

65QV-SPR

Spacer Set

290

QV290

-

35

65QV-SPR

Socket Head Protector

291

M12-291

-

36

65QV-SPR

Suction Pipe

322

SPR65322

-

37

65QV-SPR

Lower Strainer

1162

SPR65116L

Rubber
