> SLURRY PUMP PARTS > Slurry Pump Parts List, AH Slurry Pump Spares

Slurry Pump Parts List, AH Slurry Pump Spares

(672 Reviews)

TB-AH/L/M/HH

Product Brands: Tobee

Slurry Pump Wear Parts include slurry pump impeller, slurry pump liners, slurry pump throatbush, slurry pump frame plate liner insert, slurry pump casing etc, They are very easily worn-out components because the wear parts work under longtime impact of abrasive and corrosive slurries in the high speed.

price:

$399.00 $420.00

Quantity:

- + (1,200 available)
Add to Favorite Items (560)

Sales: 1,120+

Slurry Pump Wear Parts include slurry pump impeller, slurry pump liners, slurry pump throatbush, slurry pump frame plate liner insert, slurry pump casing etc, They are very easily worn-out components because the wear parts work under longtime impact of abrasive and corrosive slurries in the high speed.



Tobee® is committed to improvement of slurry pump wear parts continues with the introduction of the Hyperchrome alloy material. Slurry pump wear parts have direct connection with slurry, are very crucial to the service life of slurry pumps. The slurry pump wear parts include slurry pump impeller, slurry pump liners, slurry pump throat-bush, slurry pump frame plate liner insert, slurry pump casing etc, They are very easily worn-out components because the wear parts work under longtime impact of abrasive and corrosive slurries in the high speed. For the long service life of slurry pump wear parts, the material plays an important role here.



Tobee manufactures quality High chrome slurry pump parts, Rubber slurry pump parts, Polyurethane slurry pump parts and Ceramic slurry pump parts fully compatible with Standard AH® slurry pumps. Slurry Pump Parts are the most wear parts for the slurry pumps on the site, Slurry pump spare parts mainly include impellers, liners, seals, shaft sleeves, and bearing assembly etc. A lot of Tobee's user's use Slurry pumps in dealing with the OEM, The users are constantly faced with high costs, slow delivery times and bad customer service, so Tobee started to supply slurry pump parts that are 100% interchangeable with AH® slurry pumps.



Slurry Pump Wear Parts Benefits:
• Increased wear life – Tobee slurry pump wear parts is designed to increase wear life between 30% and 50%
• Power savings – lower pump power consumption
• Cost reduction – higher pump efficiency sustained over a longer pumping operation time
• Retrofit – new high abrasion resistance slurry pump wear parts retrofit to your current slurry pumps
• Lower NPSH requirements – results in enhanced hydraulic performance and extended wear life
• Material combinations – rubber or metal part combinations available



Slurry Pump Parts List:

Basic Part Number

Description

Basic Part Number

Description

001

Adjusting Screw

080

Stepped Washer

003

Base

081

Keeper Plate

004

Bearing Housing

083

Throatbush

005

Bearing Assembly

085

Throatbush Cotter

008

Bearing Sleeve

089

Bearing Seal

009

Bearing

090

Shaft Seal

011

Clamp Washer

092

Sump Pump Casing

012

Clamp Bolt

102

Sump Pump Column

013

Cover Plate

108

Piston Ring

015

Cover Plate Bolt

109

Shaft Sleeve O-Ring

017

Cover Plate Liner

110

Volute Liner

018

Cover Plate Liner – Throatbush

111

Packing Ring

019

Sump Pump Mounting Plate

112

Throatbush

021

Impeller – Two Vanes Open

114

Impeller – Six Vanes Open

023

Cover Plate Liner Stud

116

Sump Pump Strainer

024

End Cover

117

Shaft Spacer

025

End Cover Shim

118

Lantern Restrictor

026

Frame Plate Liner Stud

122

Seal Ring

027

End Cover Set Screw

124

Volute Cover Seal

028

Expeller

125

Volute Frame Seal

029

Expeller Ring

126

Gland Clamp Bolt

032

Frame Plate

127

Impeller – Five Vanes Open

034

Frame Plate Bolt

130

Flange

036

Frame Plate Liner

131

Gravel Pump Bowl

039

Frame Plate Liner Stud

132

Discharge Joint Ring

040

Frame Plate Liner Insert Bolt

134

Clamp Ring

041

Frame Plate Liner Insert

135

Clamp Ring

043

Frame Plate Liner

137

Impeller – Three Vanes Closed

044

Gland

138

Grease Cup Adaptor

045

Gland Bolt

143

Volute Seal Holder

046

Grease Retainer

144

Volute Seal Holder Stud

049

Impeller – Eight Vanes Closed

145

Impeller – Four Vanes Closed

051

Impeller – Two Vanes Open

147

Impeller – Five Vanes Closed

052

Impeller – Three Vanes Open

154

Sump Pump Discharge Pipe

053

Impeller – Eight Vanes Open

179

Shaft Sleeve Spacer

056

Impeller – Four Vanes Open

184

Sump Pump Flinger

058

Impeller – Six Vanes Closed

190

Suction Cover

060

Intake Joint Ring

191

Impeller – Eight Vanes Open

061

Labyrinth Locknut

204

Discharge Joint

062

Labyrinth

206

Sump Pump Impeller

063

Lantern Ring

217

Impeller O-Ring

064

Impeller Sealing O-Ring

221

Flange

066

Motor Support Bolt

239

Release Collar

067

Neck Ring

241

Lip Seal Gland

070

Shaft Key

290

Sump Pump Spacer

073

Shaft

292

Door Clamp Plate

075

Shaft Sleeve

322

Sump Pump Suction Pipe

076

Shaft Sleeve – Long Type

360

Mechanical Seal Adaptor

078

Stuffing Box

424

Mechanical Seal Shaft sleeve

079

Expeller Ring Stud
