THR6x4D Polyurethane Centrifugal Mining Slurry Pump

Product Brands: Tobee

Tobee® slurry pump are the most comprehensive range of centrifugal slurry pumps for use in mining, chemical and general industry applications. The horizontal slurry pumps are designed for heavy duty applications such as mill discharge, power sector and tailings as well as specialty applications, which are used for continuous pumping of high abrasive, high density slurries.

Add to Favorite Items (0)

Sales: 0+

Tobee^® Polyurethane Horizontal Centrifugal Slurry Pump THR4x3C with CV Drive Type, heavy duty pump, Thickener Tailings Pump, Gland Water Pump, Process Rinse Pump, Flotation Feed Pump, Spirals Product Pump, Dilute Medium Pump, Coal Heavy Media Transfer Pump.

Tobee^® THR6X4 Silica Sand Pump is end-suction, split-case, centrifugal slurry pumps have set the world standard for heavy duty abrasive pumping applications for decades. With large shaft diameters, heavy duty bearing assemblies and robust slurry pumping capacity, Tobee 6X4 pumps provide a cost-effective and ideal alternative to longer lead times and the difficulty associated with working with large multinational.

THR6X4D Polyurethane Centrifugal Mining Slurry Pump

Tobee^®Slurry Pump Detailed specification:

1. Horizontal, cantilevered, centrifugal, single stage slurry pump.

2.Long bearing life: The bearing assembly is with large diameter shaft and short overhang.

3. Wear resistant and anti abrasion wet parts: High chrome alloy and rubber etc. They are completely interchangeable with each other.

4. Easily replaceable liners: Liners are bolted to the casing.

5. Easy adjustment of impeller: An impeller adjustment mechanism is provided below the bearing housing.

6 Discharge direction can be positioned at intervals of 45 degrees.

7. Simple maintenance throat bush: the mating face of the throat bush is tapered, so the wear is reduced and removal is simple.

8. Sealing type: pcking seal,impeller sealing and mechanical seal.

9. Widely application: They are designed for handling abrasive, high density slurries in the metallurgical, mining, coal, power, building material and other industrial departments.

Tobee^®Slurry Pump Advantages:

√ Optimized structure is suitable for heavy-duty tasks, ensuring serviceability and longevity.

√ The double-casing design of our heavy duty rubber lined slurry pump allows for axial split. Made of ductile iron, the slurry pump casing is able to withstand major pressure produced within the pumping chamber. Rubber liners are made of wear resistant rubber materials, and do not stick to the outer casing for ease of maintenance and replacement.

√ The slurry pump body is fixed to the pump base or mounting base by several bolts. Users can adjust the clearance between impeller and suction liner easily from underneath the bearing support, or bearing pedestal.

√ Packing gland seal, mechanical seal and expeller seal are available to prevent slurry leakage during pumping operation

Tobee^® 6/4 D AHR Rubber Lined Slurry Pump Performance Parameters:

Model

Max. Power

(kw)

Materials

Clear water performance

Impeller

Vane No.

Liner

Impeller

Capacity Q

(m3/h)

Head H

(m)

Speed n

(rpm)

Eff. η

(%)

NPSH

(m)

6/4D-AHR

Rubber

144-324

12-45

800-1350

3-5

Tobee^® Rubber Lined Slurry Pumps Applications:

Mining & Mineral Processing
The slow running speeds of the Tobee heavy duty rubber lined slurry pump, together with the comprehensive choice of abrasion resistant alloys and elastomers, provide unrivalled performance and service life for all abrasive mining and minerals processing applications.
Chemical Process
The interchangeability of alloy and elastomer components in the same pump casing, together with a wide range of mechanical seals, make the Tobee heavy duty rubber lined slurry pump the most flexible choice for the chemical plant environment.
Sand & Gravel
Designed for easy and simple strip down and re-assembly, the Tobee heavy duty rubber lined slurry pump minimises downtime, making it the ideal choice where installed stand by pumps are not available.
Sugar Processing
The premium reliability and service life of the Tobee heavy duty rubber lined slurry pump is specified by many sugar plant engineers worldwide where uninterrupted pump operation during the sugar campaign is a critical requirement.
Flue Gas Desulphurisation
The new generation of specially formulated abrasion and corrosion resistant alloys, together with the very latest elastomer technology, positions Tobee Pumps firmly as a major supplier of pumps to the FGD industry.
Oil & Gas Exploration
Over a number of years we have developed the proven design of the Tobee heavy duty rubber lined slurry pump ranges to suit the specific demands of offshore applications. We can now offer the most reliable top side solution to erosive wear.
Industrial Applications
Wherever abrasive solids are causing premature failure of pumps, the Tobee heavy duty rubber lined slurry pump range has the right combination of performance, wear life and reliability to bring the customer the lowest cost of ownership.

Label: Dilute Medium Pump Secondary Spiral Feed Pump Spirals Product Pump Flotation Feed Pump Clarified Water Pump Thickener Tailings Pump abrasive sludge pump Product Effluent Return Pump
