Lantern Ring E063HS1P05 on 8X6E AH Horizontal Slurry Pumps

Product Brands: Tobee

Tobee® Slurry pump Lantern Ring is a ring or sleeve around a rotating shaft, There is an hole in the ring provides for forced feeding of oil or grease to bearing surfaces, It is designed for water sealing function for reducing leakage, Particularly the lantern ring is effective for cooling, and lubrication, It is usually used in packing seal and expeller seal.

price:

$210.00

Part Number:

E063HS1P05

Part Model:

8X6E AH 8/6E AH 8X6E-AH 8/6E-AH

HS Code:

8413910000

Quantity:

- + (100 available)

Add to Favorite Items (0)

Sales: 0+

Tobee^®8X6E AH Rubber Horizontal Slurry Pump Spares namely the rubber parts have direct connection with slurries, They are very easily worn-out components because they work under longtime impact of abrasive and corrosive slurries in the high speed, The wetted parts include impeller, cover plate liner, frame plate liner, throatbush, frame plate liner insert etc, These wear parts are very crucial to the service life of slurry pumps, For the long service life of pump parts, the material plays an important role here, Tobee offers rubber slurry pump parts are more suitable for delivering strong corrosive or abrasive slurries of small particle size without sharp edges.

Lantern Ring E063HS1P05 on 8X6E AH Horizontal Slurry Pumps

Tobee^®8X6E AH Rubber Horizontal Slurry Pump Spares Interchangeable parts:
√ Completely interchangeable with AH, AHR, HH, M, L horizontal slurry pumps, SP, SPR vertical slurry pumps, G,GH gravel sand pumps, AF froth slurry pumps etc

√ Metal materials code: A03, A04, A05, A06, A07, A12, A14, A25, A33, A49, A51, A61

√ Nature rubber materials code: R08, R24, R26, R33, R38, R55, R66

√ Synthetic rubber materials code: S01, S10, S12, S21, S31, S42, S44, S50

√ Polyurethane materials code: U01, U05

√ Shaft material: 45#, 40CrMo, SS304, SS316

√ Shaft sleeve material: SS410, SS420 SS304, SS316

√ Lantern ring material: 304, 316, PTFE

√ Bearing housing/ bearing end cover material: G01, D21

√ Expeller, Expeller ring: A05

√ Packing: Q05

Tobee^® Slurry Pump Lantern Ring Code:

Slurry Pump Lantern Ring Code	AH Slurry Pumps	Slurry Pump Materials
B063	1.5/1B-AH, 2/1.5B-AH	SS321
C063	3/2C-AH, 4/3C-AH	SS321
D063	4/3D-AH, 6/4D-AH	SS321
E063	6/4E-AH, 8/6E-AH, 8/6R-AH	SS321
G063	10/8F-AH, 10/8ST-AH, 12/10ST-AH, 14/12ST-AH	SS321
H063	16/14TU-AH, 18/16TU-AH, 20/18TU	SS321
Slurry Pump Lantern Ring Code	HH Slurry Pumps	Slurry Pump Materials
CH063	1.5/1C-HH	SS321
D063	3/2D-HH	SS321
E063	4/3E-HH	SS321
F063	6/4F-HH	SS321
Slurry Pump Lantern Ring Code	M Slurry Pumps	Slurry Pump Materials
E063	10/8E-M, 10/8R-M	SS321
Slurry Pump Lantern Ring Code	L Slurry Pumps	Slurry Pump Materials
A063	20A-L	SS321
BSC063	50B-L	SS321
C063	75C-L	SS321
D063	100D-L	SS321
E063	150E-L	SS321
S063	300S-L	SS321
Gravel Pump Lantern Ring Code	G(H) Gravel Pumps	Slurry Pump Materials
D063	6/4D-G	SS321
E063	8/6E-G	SS321
F063	10/8F-G, 10/8S-G, 10/8S-GH	SS321
G063	12/10G-G, 14/12G-G, 12/10G-GH	SS321
H063	16/14TU-GH	SS321

Label: Slurry Pump Parts Pump Parts mining pump parts horizontal slurry pump parts centrifugal slurry pump parts Cyclone feed 8/6 slurry pump parts mud water pump parts
