10/8F-AHR Slurry Pump for Cyclone Separation Device

Product Brands: Tobee

Tobee® AHR rubber lined slurry pumps are similar to AH metal lined slurry pump in structure. The main difference between AH and AHR is the material of wetted parts, which are natural rubber, synthetic rubber or other wear-resistant rubbers. AHR rubber lined slurry pumps are more suitable in delivering strong corrosive or abrasive slurries of small particle size without sharp edges.

price:

$8,999.00 $9,630.00

Pump Materials:

Rubber Lined Metal Lined

Seal Arrangement:

Packing seal Expeller seal Mechanical seal

Drive Type:

CV Drive DC Drive CR Drive CL Drive ZV Drive

Quantity:

- + (100 available)

Add to Favorite Items (0)

Sales: 0+

Tobee^® 10/8F-AHR Rubber Lined Slurry Pump adopts double-casing structure, It is more easy for use and maintenance. Wetted parts are made from natural rubber with durable in use, 10x8 rubber lined pump is available for gland packing seal,expeller seal or mechanical seal. The rubber lined slurry pumps are widely used in the mining, coal washing, power plant, metallurgy, petrochemical, building material, dredging, and other industrial departments etc.

Design Features:

√ Horizontal, cantilevered, centrifugal, single stage rubber lined slurry pump

√ Long bearing life: The bearing assembly is with large diameter shaft and short overhang.

√ Wear resistant and anti-abrasion wet parts: R08, R26, R55, S02, S12, S21, S31, S42 rubber materials etc.

√ Easily replaceable liners: Liners are bolted to the casing.

√ Easy adjustment of impeller: An impeller adjustment mechanism is provided below the bearing housing.

√ Discharge direction can be positioned at intervals of 45 degrees.

√ Simple maintenance throat-bush: the mating face of the throat bush is tapered, so the wear is reduced and removal is simple.

√ Sealing type: packing seal, expeller sealing and mechanical seal.

√ Widely application: designed for handling abrasive, high density slurries in the metallurgical, mining, coal, power, building material and other industrial departments.

Tobee^® 10/8 F AHR Rubber Lined Slurry Pump Performance Parameters:

Model

Max. Power

(kw)

Materials

Clear water performance

Impeller

Vane No.

Liner

Impeller

Capacity Q

(m3/h)

Head H

(m)

Speed n

(rpm)

Eff. η

(%)

NPSH

(m)

10/8F-AHR

260

Rubber

540-1188

12-50

400-750

4-12

Tobee^® THR Rubber Slurry Pumps Wetted Parts Design:

Tobee^® THR Rubber Slurry Pumps Shaft Seal Arrangement :

• Packing Seal is a general shaft seal.It applys to various pumping conditions, PTFE and Graphite materials of Packing can be used in high corrosive slurries or high temperature conditions.Using ceramic shaft sleeve,For high abrasion conditions, The ceramic shaft sleeve is available.

• Expeller seal is an impeller force of reversed centrifugal force, preventing slurry leakage. Expeller seal can be used on the single-stage pump when the positive pressure of pump inlet is no more than 10% of pump outlet pressure or on the first-stage pump in the pump series.

• Mechanical seal is advanced sealing technique without sealing leakage, integrating construction, convenient installation & replacement, various constructions suit for all kinds of conditions.

Tobee^®AHR Rubber Lined Slurry Pumps Applications:

Mining & Mineral Processing
The slow running speeds of the Tobee heavy duty horizontal slurry pump, together with the comprehensive choice of abrasion resistant alloys and rubber, provide unrivalled performance and service life for all abrasive mining and minerals processing applications.

Chemical Process
The interchangeability of alloy and rubber components in the same pump casing, together with a wide range of mechanical seals, make the Tobee heavy duty rubber lined slurry pump the most flexible choice for the chemical plant environment.

Sand & Gravel
Designed for easy and simple strip down and re-assembly, the Tobee horizontal slurry pump minimises downtime, making it the ideal choice where installed stand by pumps are not available.

Sugar Processing
The premium reliability and service life of the horizontal slurry pump is specified by many sugar plant engineers worldwide where uninterrupted pump operation during the sugar campaign is a critical requirement.

Flue Gas Desulphurisation
The new generation of specially formulated abrasion and corrosion resistant alloys, together with the very latest rubber technology, positions Tobee Pumps firmly as a major supplier of slurry pumps to the FGD industry.

Oil & Gas Exploration
Over a number of years we have developed the proven design of the horizontal slurry pump ranges to suit the specific demands of offshore applications. We can now offer the most reliable top side solution to erosive wear.

Industrial Applications
Wherever abrasive solids are causing premature failure of slurry pumps, the horizontal slurry pump range has the right combination of performance, wear life and reliability to bring the customer the lowest cost of ownership.

Label: large capacity industry slurry pump centrifugal water pump for shrimp harvesting liquid sugar pump mud transfer pump slurry pump main product cypsum slurry bleed pumps Lime stone slurry pump Gypsum Slurry Pump
