Submersible Sewage Slurry Sand Pump for Fish Pond River Dredging

Product Brands: Hydroman

Hydroman® Submersible Sewage Slurry Sand Pumps are designed with a grinder system which grinds solids into small pieces so that they can be LED away through pipes of a relatively small diameter. It is wide used to transport the sewage and filth containing grains or other corrosive medium in sewage treatment, waste water transport, drainage system, chenical engineering ,petroleum, pharmacy, mining, paper making, cement mill, steel works, power plant, coal processing and other public works etc.

price:

$720.00 $990.00

Pump Seal Arrangement:

Double Mechanical Seal

Pumps Application:

Wastewater Treatment Plants Waste Water Living Water

H.S Code:

8413709990

Quantity:

- + (50 available)

Add to Favorite Items (0)

Sales: 0+

Hydroman^® Submersible Sewage Slurry Sand Pump for Fish Pond River Dredging Deascription:

Hydroman^® Submersible Sewage Slurry Sand Pump for Fish Pond River Dredging is a heavy-duty submersible sewage pumps deviced that deals with sewage pumping. These submersible effluent waste pumps are placed in large sewers and can pump sewage directly into the sewer lines without going through the sewage treatment plant. Sump, Sewage & Effluent Submersible Pumps applicable to a wide spectrum of fields, such as raw water transfer in purifying tanks (Johkasou/septic tanks), wastewater treatment facilities, as well as drainage of sewage and wastewater.

Hydroman^® Submersible Sewage Slurry Sand Pump for Fish Pond River Dredging Specification:

Size: 50-600mm

Capacity: 8-6000m3/h
Head: 5-80m
Speed: 980-2900r/min
Temperature Range: ≤80°C
Sealing arrangement: Mechanical seal
Motor: 50Hz/60Hz, 110V/220V/380V/440V/460V/660V/1000V
Materials: Cast iron, SS 304, SS316, High chrome alloy

Hydroman^® Submersible Sewage Slurry Sand Pump for Fish Pond River Dredging Performance Parameters:

Model	Capacity Q (m3/h)	Head H (m)	Speed n (r/min)	Motor Power P (kw)	Eff. η (%)
40TWQ	8.4-14.4	14-16	2900	1.5	42-70
50TWQ	7-50.4	8-36	1450-2900	0.75-7.5	46-62
65TWQ	17.5-44.4	11-30.2	2900	2.2-4	39-72
80TWQ	20.3-72	5.7-27.5	2900	2.2-7.5	51-75
100TWQ	35-120	5.6-38.5	1450	4-15	46-80
150TWQ	49-300	5.5-44.5	1450	5.5-37	58-82
200TWQ	110-480	5.7-44.5	1450	11-75	63-83
250TWQ	420-840	7-35	980-1450	30-90	63-84.5
300TWQ	280-1140	6.7-27	980-1450	45-110	68-84.5
350TWQ	700-1800	8-40	980	45-160	68-85
400TWQ	1050-2640	12-33	980	132-160	71-85
500TWQ	1400-3600	9-22.5	980	110-200	72-85
600TWQ	2500-6000	8-25	590-740	110-315	65-78

Hydroman^® Submersible Sewage Slurry Sand Pump for Fish Pond River Dredging Structural Design:

Hydroman^® Submersible Sewage Slurry Sand Pump for Fish Pond River Dredging Application:

▪ Building waste water treatment system, sewage treatment plant, community market.
▪ Drainage of sewage from the building basements, hotel industry, and waste water from factories.
▪ Pumping surface and drainage water from garages and sprinkler systems.
▪ Collecting and settling sumps, Sewage pumping stations in Wastewater Treatment Plants.
▪ Fishery, animal husbandry, dairy farm, piggery, fecal sewage tank.
▪ Mills and factories for pumping dirty water.
▪ Water purification plants.

Submersible Sewage Pump for Municipal Aquaculture
